Description

>For under water installation in sea, river and lake bed (Depth < 15m).
>Applications are also found in special harsh situations i.e. sewers, water pressurized tunnels and galleries.
>Deepwater port network application.
>The highest standards of reliability are ensured in these demanding environments by the use of advanced optical cable design technology and utilization of high quality materials throughout.

Optical Characteristics

Parameter	Data
Wavelength(nm)	1310	1550
Attenuation(dB/km)	≤0.35	≤0.22

Reference Standards

• »»YD/T 901-2009
• »»YD/T 9771-2008

Specification

Type	Cable Diameter(mm)	Weight kg/km
GYTS33-36B1	16.3	494
GYTS333-36B1	23.1	124.3
GYTA5333-36B1	19.7	667
GYTA53333-36B1	26.1	1520

Installation

Type	Installation Method		Tension (N)	Crush N/100mm
	Installation	Operation
GYTS33-36B1	30D	15D	10000	5000
GYTS333-36B1	30D	15D	20000	6000
GYTA5333-36B1	30D	15D	10000	6000
GYTA53333-36B1	30D	15D	20000	7000
