Description

>Light weight,high tensile strength and easy installation.
>Anti-lightning.
>Long distance communication with high durability.
>LSZH sheath available.

Geometrical characteristics

Type	Diameter(mm)	Weight kg/km
GJYFXTCBY-2-12B1	4.1×8.1	37
GJYFXTCBY-14-24B1	4.6×9.5	60
GJYF2XTCBY-2-24B1	4.1×10.5	36

Reference Standards

• »»YD/T 1770-2009
• »»YD/T 9771-2008

Specification

	Data
Wavelength(nm)	1310	1550
Attenuation(dB/km)	≤0.35	≤0.22

Installation

Type	Installation Method		Tension (N)	Crush N/100mm
	Installation	Operation
GJYFXTCBY-2~12B1	20D	10D	1000	10
GJYFXTCBY-14~24B1	20D	10D	1000	1000
GJYF2XTCBY-2~24B1	20D	10D	1000	1000

Order Information
