Description
>Provide 16MHz bandwidth in 100m, typical speed rate: 20Mbps
>It's widely used for backbone of indoor audio cabling.
>High grade OFC (oxygen free copper) conductor, reliable transmission performance, meets or exceeds Cat.3 standard for both analog audio cabling and high quality digital audio system; core marked by complete color spectrum, perfect strand length for convenient installation
Reference Standards
- »»YD/T 1019-2013
- »»YD/T 926.2-2009
-
-
-
Specification
| Parameter |
Data |
| Conductor Diameter |
0.4mm |
| Insulation Diameter |
0.78±0.02mm |
| Sheah Material |
PVC |
| Individual Conductor Resistance |
≤14Ω/100m |
| DC Resistance Unbalance |
≤2.5% |
| Dielectric,DC.1min |
1KV/1min |
| Capacity Max |
5.6nF/100m |
UTP Cable
Bend Radius
D1≥10D0
Installation Bend Radius: ≥10xDiameter
Installation
<110N
(Short Term)
Operation
<20N
(Long Term)
Installation Tension:Short Term: <110N, Long Term: <20N
Indoor
Order Information
| Wooden reel, 305m(1000FT)/Reel |
 |
